|Machine weight||9 Tons|
|Cycle time||15-20 seconds|
Other settings for production
100Ton cement silo
1) Capacity(ton): 100
2)Diameter of trank(m): 3
3)Thickness of trank(mm):5
PLD800-2 batching machine
1) Weigh bucket capacity (L): 800
2) Productivity (m3/h): 72
3) Batching precision : ±1%
4) Number of material matching : 3
5) Work loading height (mm) : 2700
6) Feeding belt speed (m/s): 1
7) Power (kw): 16
8) Gross weight (kg): 4000
9) Dimension (mm):7000*3000*3100
1)Charging capacity (L): 750
2)Discharging capacity (L): 500
3)Production capacity(m3/h): ≥35
4) Max Aggregate Diameter(mm):≤60/80
5)Cycle Time (s):72
6) mixing vane rotation speed: 30.5r/min
7) mixing vane quantity :4x7
8) Power (KW): 38.6KW
9) Weight(KGS): 6800
10) Dimension ((L×W×H)mm: 2750×2400×2600
1)Overall size mm : 2500*1770*2400
2) Stack layer : 4 floors
3) Power(kw): 3
4) Weight: 2500 KG
Concrete blocks, fly ash bricks, retaining wall blocks, paving bricks, precast concrete blocks, decorative cement blocks, concrete cinder blocks, slope blocks, interlocking concrete blocks, etc.
1.Guarantee for one year and after sale service for whole life.To offer free design,free technology support and free machine maintenance trainning.
2. We will provide you with a set of spare parts for free.
Hongfa Machinery's Honor
1.One of Top Ten Influential Brands in China Brick &Tile Industry
2.China National Enterprise Abiding By Contract & Keeping Good Faith
3.Quality and Credibility of the Dual-protection Demonstration Unit
4.High and New Technology Enterprise
5.Famous Trademark of China
6.Star Enterprise with China Patent
7.AAA Grade Credit Enterprise
8.Consumer Satisfaction Unit
9.One of Top 100 building Material Industry Brands of China
10.One of Top Ten Good Faith Units
11.Advanced Exporter in Guangxi Province
12.Advance Quality Management Unit
A: We are manufacturer.
Q: How long is your delivery time?
A: 20~30 days after receipt of deposit and molds confirmation from Buyer.
Q: What is the product guarantee period ?
A: One year after installation finished at buyer's factory.
Q: What is your terms of payment ?
A: L/C, D/A, D/P, T/T, SINO SURE, WESTERN UNION, MONEY GRAM
Q: what kind of fabric is it?
A: You can send us the sample, we have a technical section,they could analyze the material structure.
Q: Could you recommend the size for us?
A: Yes, We could recommend the blanket type and size fo ryou. Based on our recommend size ,we also could provid you 2 pieces of handmade samples for your test, but you need pay the freight cost, which is $50.
Q:What is your best price?
A: We have better performance on the product quality, delivery time, package,after sale service and also payment than other suppliers, so our profit is quite low. We have to spend more on these aspects to guarantee a better performance, so we cannot guarantee these to you if you really want to cut down the price.
