Paper Tube Making Machine Ice Cream Paper Packaging Machine

Paper Cone Making Machine Ice Cream Paper Packaging MachineMachine Specification ItemSpecificationMachine Model NoDYK6-B and DYK6-H Capacity250 pcs/minMould1 SetVoltage380V/50HZThe Total Power9 KWWax Speed250 pcs /minAir Pressure0.6MPa (Dry and Clean Compressor Air)Dry Wax paper≤100gsmMaterialCommon Paper/Aluminum F

Featured Products

Paper Cone Making Machine Ice Cream Paper Packaging Machine
Machine Specification



ItemSpecification
Machine Model NoDYK6-B and DYK6-H
Capacity250 pcs/min
Mould1 Set
Voltage380V/50HZ
The Total Power9 KW
Wax Speed250 pcs /min
Air Pressure0.6MPa (Dry and Clean Compressor Air)
Dry Wax paper≤100gsm
MaterialCommon Paper/Aluminum Foil Paper/Coated Paper etc
Material Paper Gram Weight80 gsm to 150 gsm
Paper wastage rateLower than 20%
Container needed:1*20GP and 1*40GP
Standard ConfigurationElectric Controller Box
Vacuum Supplies System
Glue Spread System(Nordson or Robatech)
Finished Products Collector
Mould 1 set
Blade 10 pcs
Paper Cone Making Machine Ice Cream Paper Packaging Machine
Machine Introduction

Dayuan ice cream paper cone machine is designed according to European industrial standard. Initially developed in China, the products have achieved the CE certification and have been sold to over 70 countries in the world. With high quality and efficiency,it is an ideal choice for you to produce ice cream paper cone.

Paper Cone Making Machine Ice Cream Paper Packaging Machine



Differences between DYK6-B and DYK6-H
1.We adopt encoder to control the machine on DYK6-H, and we adopt encoder on DYK6-B, Electronic cam is more accurate for feeding, forming and gluing than encoder.

2.We adopt the belt to transport the paper on DYK6-H, and we adopt chain to transport the paper on DYK6-B, Belt is cleaner than chain and will be not pulled long, but chain will be easily pulled long.

Paper Cone Making Machine Ice Cream Paper Packaging Machine
Paper Cone Making Machine Ice Cream Paper Packaging Machine
Paper Cone Making Machine Ice Cream Paper Packaging Machine
Working Principle



The sucking mouth will suck the paper, which has been printedpreviously, from the paper bracket to the transportation chain,and then transport it to the forming mould.
>>During the transportation, the paper will be spread with hot-melt glue.
>>>Theposition, length and quantity of thermal sol can be adjustedduring the production process without stopping the machine.
>>>After the for-mation, the paper spread with glue will be automatically blown to be transported to the collection machine.
>>>The piling and counting are automatic, and the paper will be carried out according to the prearranged piling numbers withoutstopping the machine.

Paper Cone Making Machine Ice Cream Paper Packaging Machine
Company Introduction



(Dayuan Industrial Co. Ltd )
 a professional manufacturer of eco-friendly paper processing machines, following the enterprise development mission" Create Value for Customers". Founded in 1995, the company is located at Zhongshan, Guangdong, the hometown of Sun Yat Sen.

At the beginning of 1990s, the production of snack boxes(such as ice cream paper cone, hamburger box, etc) mainly relies on manual operation or machines imported from European and American countries. The poor sanitation condition and product consistency, low efficiency, expensive imported machines, long delivery period and high service cost all restricts the development of domestic paper production enterprises. With rapid development of Chinese national industry, Dayuan determinedly enters this completely new industry.

With more than 20'years exploration and development, the sales volume of four series self-innovative products(Ice Cream Paper Cone Machine, Carton Erecting Machine,Paper Cone Cup Machine and Punching Machine) rank first in the domestic market, the products have also exported to more than 70 countries and are favorably reviewed by domestic and overseas customers.

Paper Cone Making Machine Ice Cream Paper Packaging Machine
Paper Cone Making Machine Ice Cream Paper Packaging Machine



Packaging & Shipping



Packaging Dimension Case 1Case 2
Case Size1360*1160*1860mm1560*850*850mm
Gross Weight950 kg450 kg
Net Weight900 kg400 kg
Packaging Material By Strong Wooden Case
ShippingBy Sea,or as arranged
Paper Cone Making Machine Ice Cream Paper Packaging Machine
FAQ



Q:Are you factory or trading company?
A: We are factory and manufacture.

Q: Can I have sample before order?
A: Yes for sure ,sample for free ,express charge on your account .

Q: Can you make the customized paper cone ?
A: Yes , please show us your sample first .

Q: What time for delivery ?
A: Machine about 45days after get your down payment , paper cone as the quantity .

Q: Engineer oversea service ?
A: yes ,we can send engineer help you install ,training worker until to the machine normal running.

Q: What payment term ?
A: T/T 30% down payment ,balance before delivery ,or LC at sight .

Q:How to place my order?
A: Just contact us via TraderManager, E-mail, Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
